RZY200经济型圆顺贴标机特点:
通用千玻璃瓶、塑料瓶等圆柱形物体.锥形之物体可定做;
依产品材要可加装打印机。
可独立式作业.成衔接输送线。
RZY200 Economical Round Bottle Labeling Machine Features:
" Apply to the cylindrical objects, such as glass bottles, plastic bottles, conical objects can be customized; According to the product need can be mounted to the printer.
" Can Independent operation, or bridging conveyors.
技术参数/Technical Parameters:
机器尺寸/Machine size:2000L*1100W*1300H
贴标速度/Output speed:20-200pcs/min
贴标物高度/hight label object:30-280mm
贴标物厚度/Thickly labei object:30-120mm
贴标高度/Label hight:15-140mm
贴标长度/Label length:25-300mm
贴标精度/Pastes the sign precision:+1mm
纸卷内径直径/Rollinside:76mm
纸卷外径/Roll Outside Diameter:380mm
电源/Power Supply:单相220V50/60HZ3.5KW
印纸用气源/Printer with air:5Kg/cm2
机器重量/weight:150Kg
